    Embedded 8 Inch WiFi Network Industrial Panel PC with Linux OS and 300cd/m2 Brightness as Options

    Ask Lasest Price
    Brand Name : WXYUAN
    Model Number : SY080P
    Certification : CE FCC ROHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Piece/Pieces per Month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Embedded 8 Inch WiFi Network Industrial Panel PC with Linux OS and 300cd/m2 Brightness as Options

    Embedded 8 Inch WIFi Network Industrial Panel PC With Android Linux
    Display Panel Details
    Display Panel Brand
    LG,Samsung,AUO,Chimei,etc... original brand new + grade A+
    Size
    8 inch
    Customize Frame Color
    Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
    Body Material
    Durable sheet metal frame + tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
    PC Configuration
    Chipset
    Rockchip RK3566 RK3568 RK3588 RK3399...... as options
    Chipset Frequency
    Quad core upto 2.0Ghz
    Chipset integrated
    Cortex-A17+GPU Mail-T764, and others as option etc...
    Ram
    4GB DDR4 SDRAM (16GB max)
    Flash Memory
    16GB/32GB/64GB high speed (optional)
    WiFi
    802.11b/n/g Wifi Integated
    PC Configuration
    Audio
    Realtek HD ALC662 HD
    Line-In/Line-Out/Speaker out with 1W AMP Circuit
    Ethernet ports
    Realtek RTL8111EL PCI-E Gigabit Ethernet LAN RJ45 port
    HDMI ports
    Default *1 (options)
    COM ports
    Default *2 COM (options)
    USB ports
    Default *4 USB (3*USB2.0; 1*USB3.0) (options)
    Operation System
    Linux Ubuntu Debian OS Android OS etc......
    Touch Screen
    Touch Screen Type
    10-Point capacitive touchscreen as options
    Touch Screen Interface
    USB
    Surface Hardness
    Mohs' Number 7; Transmittance >75%
    Power Supply
    Input Voltage
    DC12V or 24V
    Output Rating
    ≦10W
    Environmental
    Work Temperature
    -20 ~ 60°C (-4~140°F)
    Storage Temperature
    -30 ~ 80°C (-22 ~ 176°F)
    Relative Humidity
    5~95% (Non condensation)
    Shake: SSD applied
    1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
    Shock: SSD applied
    10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
    EMC
    CE/FCC Class A
    Water-proof
    Front panel IP65

    Features.

    Our industrial panel PC are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
    Our industrial PC provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications. Our panel PC have 7 inches to 55 inches

    Specialties.

    1. Long lasting product cycle for continuity thru all phases of project rollouts and servicing
    2. Exceptional quality and highly engineered industrial monitors
    3. Delivers drift-free operation with lifetime of more than 35 million finger touches like resistive, IR, SAW, Scap, Pcap, etc
    4. All steel construction designed for harsh and industrial environments
    5. Robust design with aluminum NEMA 4/ IP65 front panel or fully steel enclosed chassis
    6. Meets NEMA 4/4x/12 and IP65 standards
    7. Multiple mounting options (75*100mm VESA mount and clamps mounting)
    8. Accuracy in high-use applications
    9. Supports Windows, Linux OS, Android, Mac OS, Ubuntu, Debian
    10. CE, FCC, RoHS, ISO9001:2008 compliance.
    11. VGA, DVI, HDMI, AV, S-Video, BNC multiple inputs/outputs optional
    12. Wide operating temperature from -30 to 80 degrees optional and supports 7/24 running

    For OEM & ODM project, customized PC configuration,

    more order quantity for more discount, pls feel free to contact with us ! Thank you !

    Embedded 8 Inch WiFi Network Industrial Panel PC with Linux OS and 300cd/m2 Brightness as Options

    Embedded 8 Inch WiFi Network Industrial Panel PC with Linux OS and 300cd/m2 Brightness as Options

    8 inch Size Drawing
